Anchor Weight Guide
BOAT SIZE ANCHOR WEIGHT
Length(ft) Weight(lbs) Bruce(lbs) Danforth*(lbs) Fortress(lbs) Plow(lbs) Yachtsman(lbs)
20-25 2,500 4.4 8-S, 5-H** 4 10 15
26-30 5,000 11 13-S, 12-H 7 15 25
31-35 10,000 11/16.5 22-S, 12-H 7/10 20 35-40
36-40 15,000 16.5 22-S, 20-H 10 25 50
41-45 20,000 22 40-S, 20-H 15 35 65
46-50 30,000 22/44 65-S, 35-H 21 45 75
51-60 50,000 44 85-S, 60-H 32 60 100
Anchor Rode Guide
BOAT SIZE ANCHOR RODE
Length (ft) Weight (lbs) Chain (dia.-inch) Nylon (dia.-inch) Length (ft)
20-25 2,500 3/16 7/16 90
26-30 5,000 1/4 7/16 135
31-35 10,000 5/16 1/2 190
36-40 15,000 3/8 9/16 225
41-45 20,000 7/16 5/8 240
46-50 30,000 1/2 11/16 315
51-60 50,000 9/16 3/4 360
*Danforth is a registered trademark. Similar-style anchors may differ significantly in
performance. **S indicates standard anchor; B indicates high-tensile anchor
Anchor Chain Marking
- One fathom equals 6 feet. There are 15 fathoms (90 feet) in a shot of anchor chain.
- Color zipties
- Heavy nylon webbing ties - Red 50' - White 100' - Blue 150' - White 200' - Red 250'
- Black at each intervening 25'
- Red = 1, White = 2, Blue = 3
- Long strip of solid with a short strip in the middle
- The LONG background color is the MOST SIGNIFICANT DIGIT, the SHORT color band in the middle is the LEAST SIGNIFICANT DIGIT. So a blue band on a white background would be the number 23. A blank (no color) band in the middle of a red background would be the number 10.
- The MOST SIGNIFICANT DIGIT (background color) represents the number of HUNDREDS OF FEET.
- The LEAST SIGNIFICANT DIGIT (band color) represents the number of 25 foot SEGMENTS that are out.
- 1 mark at 25', 2 marks at 50', 3 marks at 75', and 4 marks at 100'. That repeats for the next hundred feet.
